Hastelloy X Bolts

Hastelloy X Bolts

Rimco Overseas has Hastelloy X Bolts and has been the name to know when the errand calls for Hastelloy X clasp. HASTELLOY X compound is a Nickel Bolts-chromium-press molybde-num composite that has an excellent blend of oxidation obstruction, fabricability and high-temperature quality.

It has likewise been observed to be brilliant impervious to push consumption breaking in petrochemical applications. Hastelloy X shows great flexibility after delayed introduction at temperatures surpassing 1200, 1400, 1600°F (650, 760 and 870°C) for 16,000 hours.

hastelloy-x-manufacturer-importer-exporter-supplier-stockholder

Another quality of HASTELLOY-X clasp is that it has amazing shaping and welding attributes. It very well may be manufactured and, due to its great malleability, can be cold worked. Basic applications for hastelloy x incorporate the utilization in flying machine heater, and synthetic process parts.

It has been broadly utilized in turbine motors for burning zone parts, for example, change conduits, combustor jars, splash bars and fire holders just as in max engine thrust, tailpipes and lodge radiators. This amalgam is prescribed for use in mechanical heater applications since it has irregular impervious to oxidizing, decreasing and nonpartisan climates.

Heater moves of this amalgam were still in great condition in the wake of working for 8,700 hours at 2150°F (1177°C). HASTELLOY X amalgam is additionally utilized in the substance procedure industry for answers, stifles, impetus bolster matrices, heater confounds, tubing for pyrolysis tasks and blaze drier parts.



Hastelloy Alloy X Bolts Specifications

Materials : Hastelloy Alloy X
Standard : DIN, ASTM, BS and all International Standards
Length : 3 mm to 200 mm
Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Type : Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts.



Types of X Hastelloy Bolts

Hastelloy Hex Head Bolt Hastelloy Alloy Hex Head Bolts
Hastelloy Hex Head Bolt
Hastelloy Alloy X Hex Head Bolt
Hastelloy Square Bolt Hastelloy Alloy Square Bolts
Hastelloy Square Bolt
Hastelloy Alloy X Square Bolt
Hastelloy U Bolt Hastelloy Alloy U Bolts
Hastelloy U Bolt
Hastelloy Alloy X U Bolt
Hastelloy Eye Bolt Hastelloy Alloy Eye Bolts
Hastelloy Eye Bolt
Hastelloy Alloy X Eye Bolt
Hastelloy T Bolt Hastelloy Alloy T Bolts
Hastelloy T Bolt
Hastelloy Alloy X T Bolt
Hastelloy Hex Bolt Hastelloy Alloy Hex Bolts
Hastelloy Hex Bolt
Hastelloy Alloy X Hex Bolt
Hastelloy Lag Bolt Hastelloy Alloy Lag Bolts
Hastelloy Lag Bolt
Hastelloy Alloy X Lag Bolt
Hastelloy Counter sunk Bolt Hastelloy Alloy Counter sunk Bolts
Hastelloy Counter sunk Bolt
Hastelloy Alloy X Counter sunk Bolt



CHEMICAL COMPOSITION OF HASTELLOY X Bolts


%

Ni

Cr

Fe

Mo

Co

W

C

Mn

Si

P

S

min

balance

20.5

17.0

8.0

0.5

0.20

0.05





max

23.0

20.0

10.0

2.5

1.00

0.15

1.00

1.00

0.040

0.030



ASTM Specifications OF HASTELLOY X Bolts

Sheet/Plate Bar
B435 B572



PHYSICAL PROPERTIES OF HASTELLOY X Bolts

Density

8.23 g/cm3

Melting range

1260-1355℃



MECHANICAL PROPERTIES OF HASTELLOY X Bolts

Temp° F Tensile (psi) .2% Yield (psi) Elongation in 2” %
70 110,600 54,900 44
1000 89,000 35,600 49
1200 83,000 35,400 54
1400 67,000 34,400 53
1600 45,000 28,200 58



Characteristics of Hastelloy X Bolts

»   Outstanding oxidation resistance through 2000° F
»   Resistant to carburization and nitriding
»   Excellent high temperature strength
»   Good resistance to chloride stress-corrosion cracking



Applications of Hastelloy X Bolts

»   Gas turbines
»   Petrochemical industry
»   Industrial furnaces
»   Heat treating equipment
»   Nuclear engineering
»   Jet engine combustion chambers
»   Aircraft cabin heaters
»   Turbine exhaust components



Characteristics of Hastelloy B3 Bolts

»   Maintains excellent ductility during transient exposures to intermediate temperatures
»   Excellent resistance to pitting, corrosion and stress-corrosion cracking
»   Excellent resistance to knife-line and heat-affected zone attack
»   Excellent resistance to acetic, formic and phosphoric acids and other non-oxidizing media
»   Resistance to hydrochloric acid at all concentrations and temperatures
»   Thermal stability superior to alloy B-2



Other Grades of Hastelloy Bolts

  • Hastelloy C22 Bolt/Nut
  • Hastelloy C276 Bolt/Nut
  • Hastelloy B2 Bolt/Nut
  • Hastelloy B3 Bolt/Nut
  • Hastelloy X Bolt/Nut
