ASTM F3125 Bolts
ASTM F3125 Bolts, ASTM F3125 Bolts manufacturers, ASTM F3125 Bolts suppliers, ASTM F3125 Bolts exporters, ASTM F3125 Bolts importers, ASTM F3125 Bolts stockists. ASTM F3125 Bolts, ASTM F3125 Bolts in mumbai, ASTM F3125 Bolts manufacturers in mumbai, ASTM F3125 Bolts suppliers in mumbai, ASTM F3125 Bolts exporters in mumbai, ASTM F3125 Bolts importers in mumbai, ASTM F3125 Bolts stockists in Mumbai. ASTM F3125 Bolts, ASTM F3125 Bolts in india, ASTM F3125 Bolts manufacturers in India, ASTM F3125 Bolts suppliers in India, ASTM F3125 Bolts exporters in India, ASTM F3125 Bolts importers in India, ASTM F3125 Bolts stockists in India.
ASTM F3125 Bolts, a union and substitution of six models, A325, A325M, A490, A490M, F1852, and F2280, distributed in January 2015. The combination plans to improve modifications later on. It might likewise improve ease of use by killing duplication of arrangements that are regular to all jolt grades, types, styles, and so forth. In contrast to other jolt models, F3125 was not issued to cover another item. In this umbrella standard, the name of each jolt standard turns into a jolt review (for example A490 moves toward becoming F3125 Grade A490). The conventional jolt type assignments remain (for example Type 3 for enduring steel and Type 1 for electrical discharges high-quality steel creations). There are two jolt styles: F1852 and F2280 are alluded to as "contort off style" jolts, while the others are Heavy Hex Style jolts.
ASTM A325 AND A490 BOLTS are the high-quality jolts utilized for basic applications in North America. Their curve off sort partners are F1852 and F2280, ASTM benchmarks A325M and A490M cover the metric renditions. By and large, jolt gauges are presented when new items end up accessible and the interest exists. ASTM Standards A325 and A490 have been around for 50 years, though A325M, A490M, F1852, and F2280 were discharged in later dates. Each of the six gauges incorporate numerous arrangements that are basic to at least two principles just as arrangements that are one of a kind to one.
Rimco is the biggest producer Of ASTM F3125 Bolts Fastener territory and stock in all sizes of fasteners, nuts, washers, hex attachment screws, metal string screws, self-tapping, wood tightens and security items metric, magnificent and in all evaluations. ASTM F3125 Bolts is the standard particular for compound steel and hardened steel jolts utilized in high-temperature or high-weight conditions or other extraordinary reason applications. Rimco has been assembling ASME SF 3125 Grade A325 Bolt, ASTM F3125 Bolts Head Hex Bolts and custom clasp as prerequisite of client.
ASME F3125 Alloy Steel Bolt determination is intensely used in oil and concoction development applications. ASTM F3125 Bolts 12-Point Structural Bolt are spotless, brilliant, smooth, and acclaimed for their sturdy execution and rough development. The fasteners, top screws, and studs will be fabricated from material having a substance creation fitting in with the necessities determined. The ASTM F3125 Bolts Fasteners has some one of a kind highlights to offer, for example, Optimum quality, Corrosion opposition, Chemical obstruction, Rugged plan, High conductivity, Smooth surface, and so on.
F3125 Bolt Types
| Grade | Min Strength, Tensile | Type | Style |
|---|---|---|---|
| A325 | 120ksi min | 1 or 3 | Heavy Hex Head |
| A325M | 830MPa min | 1 or 3 | Heavy Hex Head |
| F1852 | 120ksi min | 1 or 3 | Twist-Off/TC |
| A490 | 150-173ksi | 1 or 3 | Heavy Hex Head |
| A490M | 1040MPa | 1 or 3 | Heavy Hex Head |
| F2280 | 150ksi | 1 or 3 | Twist-Off/TC |
Type 1 – 150ksi – alloy or alloy boron steel Type 3 – weathering Steel |
|||
ASTM F3125 BoltsIndustrial Applications
- ASTM F3125 Boltsuses in Aircraft Exhaust Manifolds
- ASTM F3125 Boltsuses in Off-Shore Oil Drilling Companies
- ASTM F3125 Boltsuses in Power Generation
- ASTM F3125 Boltsuses in Petrochemicals
- ASTM F3125 Boltsuses in Gas Processing
- ASTM F3125 Boltsuses in Specialty Chemicals
- ASTM F3125 Boltsuses in Pharmaceuticals
- ASTM F3125 Boltsuses in Pharmaceutical Equipment
- ASTM F3125 Boltsuses in Spiral Welded tube for burner pipes and flues
- ASTM F3125 Boltsuses in Sea Water Equipment
- ASTM F3125 Boltsuses in Heat Exchangers
Chemical Requirements- Type 1
| Heat Analysis | 120ksi, % | 150ksi, % |
|---|---|---|
| Carbon | 0.30 – 0.52 | 0.30 – 0.48* |
| Manganese | 0.60 min | 0.60 min |
| Phosphorus | 0.035 max | 0.035 max |
| Sulfur | 0.040 max | 0.040 max |
| Silicon | 0.15 – 0.30 | - |
| Boron | 0.003 max | 0.003 max |
| Copper | - | - |
| Nickel | - | - |
| Chromium | - | - |
| Molybdenum | - | - |
Chemical Requirements- Type 3
| Heat Analysis | 120ksi, % Comp A | 120ksi, % Comp B | 120ksi, % Index | 150ksi, % Index |
|---|---|---|---|---|
| Carbon | 0.33 – 0.40 | 0.38 – 0.48 | 0.30 – 0.52 | 0.30 – 0.53 |
| Manganese | 0.90 – 1.20 | 0.70 – 0.90 | 0.60 min | 0.60 min |
| Phosphorus | 0.035 max | 0.035 max | 0.035 max | 0.035 max |
| Sulfur | 0.040 max | 0.040 max | 0.040 max | 0.040 max |
| Silicon | 0.15 – 0.30 | 0.30 – 0.50 | ||
| Copper | 0.25 – 0.45 | 0.20 – 0.40 | 0.20 – 0.60 | 0.20 – 0.60 |
| Nickel | 0.25 – 0.45 | 0.50 – 0.80 | 0.20 min* | 0.20 min* |
| Chromium | 0.45 – 0.65 | 0.50 – 0.80 | 0.20 min | 0.20 min |
| Molybdenum | 0.06 max | 0.10 min* | 0.10 min* |
Mechanical Properties
| Grade | Tensile, ksi | Yield, ksi min | Elongation, % min | RA, % min |
|---|---|---|---|---|
| 120ksi (A325/F1852) | 120 min | 92 | 14 | 35 |
| 150ksi (A490/F2280) | 150-173 | 130 | 14 | 40 |
F3125 Marking Requirements & Matching Components
| 120ksi, Type 1 | 120ksi, Type 3 | 150ksi, Type 1 | 150ksi, Type 3 | |
|---|---|---|---|---|
| Marking | A325 | A325 | A490 | A490 |
| Nut, Plain | A563 DH | A563 DH3 | A563 DH | A563 DH3 |
| Nut, Coated | A563 DH | A563 DH3 | A563 DH | A563 DH3 |
| Washer | F436-1 | F436-3 | F436-1 | F436-3 |
ASTM F3125 BoltsChemical Composition
| Heat Analysis | 120ksi Type 1, % | 150ksi Type 1, % | 150ksi Type 3, % |
| Carbon | 0.30 – 0.52 | 0.30 – 0.48 | 0.30 – 0.53 |
| Manganese | 0.60 min | 0.60 min | 0.60 min |
| Phosphorus | 0.035 max | 0.035 max | 0.035 |
| Sulfur | 0.040 max | 0.040 max | 0.040 |
| Silicon | 0.15 – 0.30 | - | |
| Boron | 0.003 max | 0.003 max | |
| Copper | - | - | 0.20 – 0.60 |
| Nickel | - | - | 0.20* min |
| Chromium | - | - | 0.45 min |
| Molybdenum | - | - | 0.10* min |
Available ASTM F3125 BoltsOther Types
- ASTM F3125 Bolts Bolts
- ASTM F3125 Bolts High Strength Structural Bolts
- ASME F3125 Carbon Steel Screws
- ASTM F3125 Bolts Hex Headed Bolts
- ASTM F3125 Bolts Heavy Hex Bolts Exporter
- F3125 Alloy Steel Studs Supplier
- ASME F3125 Bolts Stockist
- ASTM F3125 Bolts Threaded Rods
- ASTM F3125 Bolts Hex Head Bolts Manufacturer
- ASTM F3125 Bolts Hexagon Head Screw Stockist
- ASTM F3125 Bolts Studbolts Supplier
- ASTM F3125 Bolts Grade A325 Bolts Distributor
- ASTM F3125 Bolts Grade A490M Bolts Dealer
- ASTM F3125 Bolts Carbon Steel studs Stockholder
- F3125M Carbon Steel Threaded Rods Manufacturer in India
- ASTM F3125 BoltsM Minimum Tensile Strength
